  • Pilot scale FREEZE DRYER

  • SPECIRICATION
























































[For Bio/Food industry]		 LP 50 LP 100 LP 200 LP 300 LP 500
Totally Ice Capacity 50 liters 100 liters 200 liters 300 liters 500 liters

Condencer

Temperature

Below -85℃

Self

Temperature

-45 to +80℃
Self Areas 3.2m²(0.4m²/EA) 6.4m²(0.8m²/EA) 13.2m²(1.2m²/EA) 19.8m²(1.8m²/EA) 33.6m²(2.5m²/EA)
Self Quantity 8 + 1 11 + 1 14 + 1
Matrial STS 316 (Chamber/Shelf) / Calibration service
Self Dimension (WxDxH mm) 500x800x18 805x1005x18 1005x1205x25 1210x1510x25 1510x1650x25
Ext. Dimension (WxDxH mm) 1450x2003x2140 1600x2415x2210 2970x2855x2160 3500x3390x2375 3516x4616x2347
Electrical 380/400/440/480V 3Ph 50/60Hz
Refrigeration System 7.5HP x 2EA 10HP x 2EA 30HP x 2EA 40HP x 2EA 30HP x 4EA
Vacuum vol.(LPM) 841 1,600 4,000 6,680 14,000
